Fasteners |
Specification |
Fasteners Length |
3 mm to 200 mm |
Fateners |
UNF, BSW, BSF, METRIC, UNC, or as required |
Standard of Fasteners |
IS1364, ISO 4014, ISO 4017, DIN 933, DIN 931, BS 1083, BS 1768, ASME B18.2.1, JIS B1180, DIN 558, ISO 4018, DIN-EN14399-4, DIN 601, ISO 4016, CSN 21301, EU 24016, DIN 7968, DIN7990, ASME B18.2.1, B18.5 |
Threads Configuration |
ASME B1.1 2A/3A – 2B/3B Inch Unified threads and B1.13M 6h-6G Metric Coarse tdreads |
Certification |
Dual Certified As per ASTM & ASME Codes |
Threads |
Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
Production process |
M24-M100: hot forging, M2-M24: Cold Forging, for custom-made connecting element machining and CNC |
Head drive of Fasteners |
Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
Packing of Fasteners |
IN BULK: canton, pallet, Small Boxs / carton/pallet, or customer request |
Surface Coating |
PTFE Coated Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
Fasteners finishing |
Coatings & Finishes: Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating, Dacroment, nickel-plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide, |
Grades |
Stainless Steel |
200 Series - 201, 205, 202. 300 Series 301, 302, 303, 308, 309, 304, 304L, 309S, 310, 310S, 314, 317, 317L, 316, 316L, 316TI, 321, 347. 400 Series 405, 430F, 436, 409, 429, 430, 430FSe, 434, 442, 446, 403, 410, 414, 416, 416Se, 431, 440A, 420, 420F, 422, 440B, 440C. 500 Series - 501, 502. 600 Series - 630 (17-4 PH). |
Carbon Steel |
ASTM / ASME A 335 GRP 1 , P 5 , P 9 , P 11 , P 12 , P 22 , P 23 , P 91 |
Nickel Alloys |
Nickel Alloys 200, Nickel Alloys 201 |
Hastelloy |
Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000, Hastelloy C-4, Hastelloy X, Hastelloy B, Hastelloy N, Hastelloy G |
Inconel |
Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750 , Inconel 690, Inconel 602, Inconel 617, Inconel 925, Inconel A-289, Inconel AL-6XN, AL-904L |
Monel |
Monel 400, Monel k500 |
Duplex Steel |
ASTM / ASME SA 790 UNS NO S 31803 , S 32205 , S 32550 , S 32750 , S 32760. |
Super Duplex Steel |
S32750 |
Copper Nickel |
Cu-Ni 90/10 (C70600), Cu-Ni 70/30 (C71500), C70250, C75700, C95800, C71510, C72500 |
